Developer Guide ​

This guide explains the architecture, key modules, and how to extend SaLED.

Repository layout ​

  • Backend: backend/saled
    • app/main.py: FastAPI app, CORS, health, router registration.
    • app/routers: API endpoints for transcribe, summary, chat, retranslate.
    • core/services: Business logic; stateless where possible, with in-memory job/result stores.
    • core/models: Adapters like WhisperTranscriber and LLMService.
    • cli: Typer-based CLI for model management and local transcription.
  • Frontend: frontend Next.js UI.

Backend architecture ​

  • FastAPI app exposes REST + WebSocket.
  • Request-scoped headers: X-Request-ID, X-Process-Time-Ms added by middleware.
  • Routers:
    • Transcribe: start job, list jobs, get status, get result, live WebSocket stream.
    • Summary: start job, get status, get result.
    • Chat: synchronous responses to transcript-grounded prompts; list available models.
    • Retranslate: reprocess segment from uploaded clip or from full audio registered by job.

Services ​

TranscriptionService ​

  • Saves uploaded file, assigns job_id, spawns background processing.
  • Converts to WAV; chunk-based processing for long audio (60s chunks, 10s overlap).
  • Real-time progress via _update_job_status and get_segments_generator.
  • Diarization: tries PyAnnote; if unavailable, uses feature/rule-based fallbacks.
  • Results in-memory: jobs, results, segments_cache, and job_file_paths for retranslation.

SummaryService ​

  • Uses LLMService to generate a summary and extract topics.
  • Tracks job status and results in-memory.

ChatService ​

  • Wraps LLMService.chat with a transcript-aware system prompt.
  • Returns assistant message, model used, and token usage.

RetranslateService ​

  • Keeps a map of job_id → audio file path for full-audio segment extraction.
  • Extracts a time range to WAV and runs WhisperTranscriber on the slice.

Getting started (development) ​

Prerequisites ​

  • Linux/macOS with Bash
  • Git for version control
  • NVM for Node.js and npm frontend environment
  • UV for Python backend environment

1) Clone the repo ​

bash
git clone https://github.com/Sang-Buster/SaLED.git
cd SaLED

2) Install dependencies ​

Use the Makefile helpers:

bash
make install
# or
./run.sh install

This will:

  • Backend: create/refresh a uv virtual environment and sync Python deps in backend/saled.
  • Frontend: install npm packages in frontend.

Optional: install pre-commit hooks

bash
uv add ruff pre-commit
pre-commit install

3) Start development servers ​

bash
make dev
# or
./run.sh dev

To run only one side:

bash
make backend    # FastAPI only
make frontend   # Next.js only

4) Verify health ​

5) First transcription ​

Use the API UI at http://localhost:8000/docs or curl:

bash
curl -X POST "http://localhost:8000/api/transcribe/" \
  -F "file=@backend/saled/demo.wav" \
  -F "model_name=tiny.en" \
  -F "diarize=true"

Response contains job_id. Poll status:

bash
curl "http://localhost:8000/api/transcribe/status/<job_id>"

Fetch result:

bash
curl "http://localhost:8000/api/transcribe/result/<job_id>"

6) Using the CLI (optional) ​

From backend/saled:

bash
./cli.py --help
./cli.py model list
./cli.py model download tiny.en
./cli.py transcribe ../../demo.wav

Troubleshooting ​

  • Port conflicts: run make clean to kill prior servers.
  • Missing models: run ./cli.py model list and ./cli.py model download <name>.
  • CORS or 500s: check backend logs; every response includes X-Request-ID to trace.
  • Long audio: progress is chunked; for live updates, connect to WebSocket /api/transcribe/live/{job_id}.

Adding a new API route ​

  1. Create a router in app/routers/<feature>.py with Pydantic models.
  2. Register it in app/main.py with app.include_router.
  3. Implement logic in core/services/<feature>_service.py.
  4. Add tests in backend/saled/tests.

Extending transcription ​

  • Models: integrate new Whisper variants by extending WhisperTranscriber or mapping in MODEL_REPO_IDS.
  • Progress: emit granular messages via _update_job_status.
  • Diarization: plug in better pipelines; ensure fallbacks remain robust.

Frontend integration notes ​

  • The UI expects REST endpoints at /api/<feature> and a WebSocket at /api/transcribe/live/{job_id}.
  • CORS is permissive by default; tighten for production.

Production considerations ​

  • Persistence: move jobs/results from memory to a store (Redis/Postgres/S3 for blobs).
  • Background workers: offload long jobs to a task queue (RQ/Celery/Arq) to isolate API.
  • Rate limits/auth: introduce auth middleware and quotas.
  • Observability: structure logs with request_id; export metrics.
  • Model assets: pre-fetch and cache models using the CLI or at container build time.

Testing and linting ​

  • Tests live under backend/saled/tests.
  • Lint: make lint runs frontend Prettier/ESLint and backend Ruff.
